mjlipari188:
Hello everyone! This is my first post here. I’m relatively new to dulcimers but have taken a keen interest in them. I am a life-long guitar player. I had a unique opportunity to purchase this Sunhearth dulcimer and I’m looking to get it back to its working state.
I believe it is a 3-string instrument and possibly a DIY kit? The construction of it is just a bit confusing to me. It’s missing the tuning heads, nut, and bridge, and I was expecting to see nails or nail holes for loop-end strings, but there is nothing like that on it. Just a latch and one nail. The whole top part also comes off.
I set up guitars pretty regularly but I want to get some advice on this dulcimer before I buy or do anything. It seems to be in great shape and I would love to give it life again. I sincerely appreciate any and all advice / insight you can provide. Thank you for your help, looking forward to hearing from you!! :)
Hi MJ, this appears to be a Standard Teardrop, AD2. The signature is genuine Walter Martin.
How was the dulcimer supplied? Was the top separate? or did you disassemble it? It is unusual is several regards:
- 1. It is an unfinished instrument.
- The saddle slot has not been cleared and cleaned
- There are no string pins
- The pegholes have not been reamed
- The top linings show signs of being prepped for gluing the top on, but there is no evidence that the top was ever glued on then removed, in the area you photographed. Walt used wood glue (aliphatic resin) which is not easily reversible when applied to redwood (a wood very prone to splitting under any such separating pressure).
- The hook latch on the tailblock holding the fretboard in place is not placed to hold the fretboard firmly, nor in its correct position
Unfortunately, Walt did not begin keeping a registry of his dulcimers until he had built 100, so yours is the last unregistered Sunhearth. If you like, I can add it to the registry. I'll need your name, date of acquisition, and if possible, who you acquired it from (perhaps the original owner).
You could assemble the instrument and outfit it as originally designed if you like. You may be able to find enough detail at my website, bearmeadow.com, to do that. Several people have written me over the years to say they used the info under the various menus to build their first dulcimers. But putting together a Sunhearth is essentially what is described there, and illustrated. Or send me a private message message with your email and I'll send you details.
